| 主要(yao)技術(shu)參(can)數 | TECHNICAL DATA | UNIT | YP12090 |
| 最(zui)大壓制力 | Max.Pressing Force | kN | 120000 |
| 最大(da)頂(ding)出力 | Max.Ejecting Force | kN | 400 |
| 動梁最大行程 | Max.Plunger Stroke | mm | 220 |
| 動梁下平面與(yu)工作(zuo)臺面最小間距(ju) | Min.Distance between Press Plunger and Table | mm | 580 |
| 動梁(liang)下平面(mian)與工作臺面(mian)最大間距 | Max.Distance between Press Plunger and Table | mm | 800 |
| 左右(you)立柱間凈空 | Clearance between Columns | mm | 3030 |
| 動梁工作(zuo)面(mian)前(qian)后寬度 | Useful Width of Plunger | mm | 1400 |
| 工作臺面前(qian)后寬度 | Width of Press Table | mm | 1620 |
| 最(zui)大填(tian)料深度 | Max.Filling Depth | mm | 80 |
| 空循環次數可(ke)達 | Working Cycles in idle Stroke | mm-1 | 14 |
| 周期中加壓次數 | Strokes Per Cycle | times | 2～5 |
| 主電(dian)機功(gong)率 | Power of the Main Motor | kW | 220 |
| 系(xi)統(tong)裝油量(liang) | System Oil Capacity | L | 3800 |
| 系統耗氣(qi)量 | Air Consumption | m3/h | 0.5 |
| 常溫水(shui)流量 | Water Consumption at 24℃ | m3/h | 45 |
| 主機重量(liang) | Weight of the Press Body | t | 340 |
